 | Industrial grade True Union design, 1/4-turn shutoff. Basic On-Off operation.
Blocked Seal Carrier
Double O-ring Stem Seal
PTFE Seats
235 psi @ 73°F (23°C) (flanged 150 psi)
115 VAC standard, optional voltages available
High Impact PP NEMA 4x Enclosure, SS316 Fasteners
2-Position with Stem-mounted Visual Open/Close Indicator |
 | Industrial grade True Union design, 1/4-turn shutoff for a wide
range of applications. Full-featured actuator can be custom configured
with add-on accessories.
Blocked Seal Carrier
Double O-ring Stem Seal
PTFE Seats
1/2″ -4″ 235 psi @ 73°F (23°C)
6″ and all flanged 150 psi @ 73°F (23°C)
115 VAC standard, optional voltages available
2-Position Operation with 2-SPDT Limit Switches
NEMA 4 Enclosure, Powder Coated
Manual Override (shown)
Position Indicator |
 | Industrial grade True Union design, 1/4-turn shutoff for a wide
range of applications. Full-featured actuator can be custom configured
with add-on accessories.
Blocked Seal Carrier
Double O-ring Stem Seal
PTFE Seats
1/2″ -4″ 235 psi @ 73°F (23°C)
6″ and all flanged 150 psi @ 73°F (23°C)
80 psi Operating Pressure, other options available
2-Position Air-Air or Air-Spring Closed (optional spring open)
Dual Rack & Pinion with Adjustable Stops
Manual Override
Position Indicator |
 | Industrial grade valve with patented seat design uses no liner.
Eliminates seat-creep and reduces operating torque. Full-featured
actuator can be custom configured with add-on accessories. Optional Lug,
True Lug
Solid SS316L Stem
ANSI Class 150 Bolt Pattern
150 psi @ 73°F (23°C) (Thru 12″),
14″-100 psi, 16″-85 psi,
18″-70 psi, 20″-24″-50 psi
115 VAC standard, optional voltages available
2-Position Operation with 2-SPDT Limit Switches
NEMA 4 Enclosure, Powder Coated
Declutchable Manual Override
Position Indicator |
 | Industrial grade valve with patented seat design uses no liner.
Eliminates seat-creep and reduces operating torque. Full-featured
actuator can be custom configured with add-on accessories. Optional Lug,
True Lug
Solid SS316L Stem
ANSI Class 150 Bolt Pattern
150 psi @ 73°F (23°C) (Thru 12″)
14″-100 psi, 16″-85 psi,
18″-70 psi, 20″-24″-50 psi
80 psi Operating Pressure, other options available
2-Position Air-Air or Air-Spring Closed (optional spring open)
Dual Rack & Pinion with Adjustable Stops
Manual Override
Position Indicator |
 | Industrial grade valve with factory assembled lug inserts. Patented
seat design uses no liner. Eliminates seat-creep and reduces operating
torque. Full-featured actuator can be custom configured with add-on
accessories.
Solid SS316L Stem
ANSI Class 150 Bolt Pattern
150 psi @ 73°F (23°C)
115 VAC standard, optional voltages available
Zinc or SS Lug Inserts
2-Position Operation with 2-SPDT Limit Switches
NEMA 4 Enclosure, Powder Coated
Declutchable Manual Override
Position Indicator |
 | General purpose industrial grade sealed unit design, 1/4-turn shutoff. Basic On-Off operation.
Maintenance-free
PTFE Seats
235 psi @ 73°F (23°C) (flanged 150 psi)
115 VAC standard, optional voltages available
High Impact PP NEMA 4x Enclosure, SS316 Fasteners
2-Position with Stem-mounted Visual Open/Close Indicator |
 | Industrial grade Weir-type design, excellent for throttling and use
with viscous fluids. Full-featured actuator can be custom configured
with add-on accessories.
Stainless Steel Hardware
235 psi @ 73°F (23°C) — sizes 1/2″-2″
(flanged & PTFE diaphragm-150 psi),
2-1/2″-4″-150 psi
40-140 psi Variable Operating Pressure
Linear Action Operation with Preset Stops
Air-Air or Air-Spring Closed (optional spring open) |
| General Purpose True Union design, 1/4-turn shutoff. Basic On-Off operation.
Blocked Seal Carrier
Teflon®/HDPE Seats
235 psi @ 73°F (23°C) (flanged 150 psi)
115 VAC standard, optional voltages available
High Impact PP NEMA 4x Enclosure, SS316 Fasteners
2-Position with Stem-mounted Visual Open/Close Indicator |
